2009 Jeep Wrangler Specs

2009 Jeep Wrangler Specifications

If you'd like to learn about how some of these numbers affect your driving experience, click here.



2009 Jeep Wrangler Powertrain

Engine 3.8L SMPI V6
Displacement (cu in) 230.5
Horsepower (lb-ft @ rpm) 202@5,000
Torque (SAE net @ rpm) 237@4,000
Axle Ratio (:1)
    6-speed manual
    4-speed automatic      		3.21 Std., 3.73 Opt., 4.10 Std. - Rubicon
3.73 Std., 4.10 Std, - Rubicon
Fuel System Sequential multiport, electron fuel injection
Fuel Recommendation Unleaded regular, 87 octane (R+M)/2
Transmission
    6-speed manual with overdrive, synchronized in all gears, multirail shift,
     system with top-mounted shift lever
    4-speed automatic with overdrive clutch hydraulic actuation, dual-mass flywheel
     system, electronically controlled converter clutch		 Std.

Opt. (Std. on 2WD Unlimited models)
Overall Top Gear (:1) 2.69 Std., 3.44 Std. - Rubicon
Engine Construction Cast-iron block, aluminum alloy heads
Electronic Throttle Control Std.
Valve System OHV, 12 valves, roller camshaft followers, hydraulic lifters
Mounts Cast-iron mounting brackets with tuned 3-point dual
preloaded elastomeric bushings
Exhaust System Long-life, stainless steel



2009 Jeep Wrangler Electrical System

Battery 600 CCA, maintenance free
Fan On demand 2-speed electric with thermally activated circuit breaker



2009 Jeep Wrangler Four-Wheel-Drive-System (transfer case)

NV241 Gll Command-Trac® (includes off-road skid plates), part-time, 2-speed, shift-on-fly, 2.72:1 low gear ratio Std. - All 4x4 models, except Rubicon
NV241 or Rock-Trac® (includes off-road skid plates), part-time, 2-speed, shift-on-fly, 4:0:1 low gear ratio Std. - Rubicon



2009 Jeep Wrangler Gear Ratio/Craw Ratio (manual transmission, standard axle ratio)

Model First Gear Ratio Transfer Case (4LO) Axle Ratio Crawl Ratio
Rubicon 4.46 4.00 4.10 73:1
Unlimited Rubicon 4.46 4.00 4.10 73:1
Sahara 4.46 2.72 3.21 38.9
Unlimited Sahara 4.46 2.72 3.21 38.9
X 4.46 2.72 3.21 38.9
Unlimited X 4.46 2.72 3.21 38.9



2009 Jeep Wrangler Capacities/Weights/Towing (4WD) (pounds unless otherwise specified)

Mid-Mounted Fuel Tank (gal) 2-door/4-door 18.6/22.5
Base Curb Weight 2-door 3,849
2WD/4WD 4-door 4,032/4,231
Payload Capacity (includes occupants and cargo) 1,000
Maximum Gross Combined Weight Rating 2-door/4-door, Class II towing 7,500/9,200
Maximum Loaded Trailer Weight,2-door/4-door
  2-door  with Trailer Tow Group/4-door with Trailer Tow Group		 Std. - 1,000
2,000/3,500
Tongue Load Limit 350



2009 Jeep Wrangler Ramp Travel Index (RTI) (20-degree ramp)

Rubicon (sway bar connected/disconnected) 638/822
Unlimited Rubicon (sway bar connected/disconnected) 484/644



2009 Jeep Wrangler Body/Suspension/Chassis

Body Design - Boxed steel frame with crushable, hydroformed front rail tips .
Suspension - Live solid axles, 5-link front/real coil springs, leading arms,
track/stabilizer bars and front steering damper		 .
Shock Absorbers (gas-charged) High-pressure monotube with Low-Speed
Tunable valve technology		 Std. - Rubicon/Sahara
Front Sway Bar Disconnect System Opt. - X, Std. - Rubicon
Steering Type Power, recirculating ball with damper
Overall Ratio 2-door/4-door 16:7:1/14.7:1
Turning Diameter (curb-to-curb, with P225/75R16 tires)(ft) 2-door/4-door 34.9/41.2
Steering Turns (lock-to-lock) 2-door/4-door 3.5/3.1



2009 Jeep Wrangler Brake System

Four-Wheel Disc - Hydraulic, power-assisted, 11..9" vented/12.4" solid rear
Electronic Stability Program Four-wheel disc antilock, with on- and off-road calibrations, 4-channel, active
wheel-speed, vehicle-speed, steering-wheel-angle, yaw-rate and lateral-acceleration sensors, vehicle stability
management with 3-stage activation switch, all-speed traction control, Brake Assist, Electronic Roll Mitigation
and Electronic Brake Distribution
Parking Break Type Drum-in-hat, off-road rated



2009 Jeep Wrangler Interior Dimensions

Seating Capacity 2-door front/rear, 4-door front/rear 2/2, 2/3
Head Room front
   rear		 41.3"
40.3"
Leg Room front
   rear, 2-door/4-door		 41.0"
35.6"/37.2"
Shoulder Room front
   rear, 2-door/4-door		 55.8"
61.6"/56.8"
Hip Room front
   rear, 2-door/4-door		 55.6"
44.7"/56.7"
Front-Seat Travel 9.4"
Front-Seat Volume Index (cubic feet) 54.8"
Rear-Seat Volume Index (cubic feet), 2-door/4-door 48.3"/48.4"
Cargo Volume (cubic feet) rear seat folded and tumbled, 2-door
   rear seat folded, 2-door/4-door
   behind rear seat 2-door/4-door		 61.2"
56.5"/82.0"
17.2"/46.4"
Cargo Liftover Height 2-door/4-door 27.8"/31.4"



2009 Jeep Wrangler Exterior Dimensions

Wheelbase 2-door/4-door 95.4"/116.0"
Overall Length 2-door/4-door 163.8"/184.4"
Overall Width 2-door/4-door 73.7"/73.9"
Track front/rear 61.9"/61.9"
Height 2-door/4-door 72.3"/72.3"
Ground Clearance (at curb weight) (Rubicon) 10.5"
Approach Angle 2-door/4-door 44.3"/44.4"
Departure Angle 2-door/4-door 40.4"/40.5"
Breakover Angle 2-door/4-door 25.3"/20.8"



The preceding specifications were taken from the official 2009 Jeep Wrangler Catalog, available at your local Jeep Dealer.
